1. ETERNUS AX/HX Installation
Installation Specifications
Site Planning Guide16
ETERNUS HX6100
Each installation specification is shown below.
• Installation specifications: Table 10
• Sound level of the drive shelf: Table 11
• Efficiency and the power factor of the power supply unit: Table 12
Table 10 Installation Specifications (ETERNUS HX6100)
Item ETERNUS HX6100
Dimensions
(W × D × H)
Controller shelf 483 × 828 × 175 mm (4U)
DS212C 3.5" type drive shelf 480 × 505 × 87 mm (2U)
DS224C 2.5" type drive shelf 480 × 484 × 85 mm (2U)
DS460C 60-drive type drive shelf 486 × 922 × 176 mm (4U)
Power distribution unit (2U) (*1) (485 × 123 × 44 mm) × 2
Maximum weight (*2)
(*3)
3.5" type controller shelf 49.2 kg (53.2 kg)
DS212C 3.5" type drive shelf 28.7 kg (32.7 kg)
DS224C 2.5" type drive shelf 24.4 kg (28.4 kg)
DS226C 2.5" type drive shelf 22.2 kg (26.2 kg)
DS460C 60-drive type drive shelf 112 kg (116 kg)
Power distribution unit (2U) (*1) (3.0 kg) × 2
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50 Hz / 60 Hz
Maximum power
consumption (*2)
Controller shelf AC100 – 120V 1,512 W (1,543 VA)
AC200 – 240V 1,470 W (1,500 VA)
Drive shelf DS212C
3.5" type
AC100 – 120V 338 W (345 VA)
AC200 – 240V 332 W (340 VA)
DS224C
2.5" type
AC100 – 120V 396 W (405 VA)
AC200 – 240V 389 W (398 VA)
DS460C 60-
drive type
AC100 – 120V -
AC200 – 240V 1,541 W (1,558 VA)
Maximum configuration
(*4)
AC100 – 120V 25,272 W (22,243 VA)
AC200 – 240V 24,810 W (21,900 VA)
Maximum heat
generation (*2)
Controller shelf AC100 – 120V 5,443 kJ/h
AC200 – 240V 5,292 kJ/h
Drive shelf DS212C
3.5" type
AC100 – 120V 1,217 kJ/h
AC200 – 240V 1,195 kJ/h
DS224C
2.5" type
AC100 – 120V 1,426 kJ/h
AC200 – 240V 1,400 kJ/h
DS460C 60-
drive type
AC100 – 120V -
AC200 – 240V 5,548 kJ/h
Maximum configuration
(*4)
AC100 – 120V 90,979 kJ/h
AC200 – 240V 89,316 kJ/h
Maximum amount of
exhaust air
Controller shelf -
Drive shelf 2.5" type / 3.5" type -
60-drive type -
