1. ETERNUS AX/HX Installation
Package Size
Site Planning Guide27
Package Size
The ETERNUS AX/HX is shipped in cardboard boxes or in a rack. These boxes may not fit through some doorways
or elevators. To make sure that the ETERNUS AX/HX can be moved to the installation site, carefully check the
transport route information.
The following table shows the package size and the maximum package weight of each component.
Table 15 Package Size
*1: The size includes the ramp (slope) for the crate package.
*2: This value is used when shelves are not installed in the rack.
*3: When an order for optional drives to be installed in the factory is placed, shelves are shipped with the drives prein-
stalled. When optional drives are ordered without preinstallation, each drive is shipped in an individual package, or in a
box of 6 or 10 drives.
Component Package size (W × D × H) Maximum weight
Reinforced cardboard for 19-inch racks 950 × 1,450 × 2,190 mm (*1) Approximately 240 kg (*1)
(*2)
Reinforced cardboard for 19-inch wide racks 1,030 × 1,550 × 2,170 mm (*1) Approximately 260 kg (*1)
(*2)
Controller shelf 2.5" type 810 × 490 × 710 mm 44.5 kg
3.5" type 810 × 490 × 710 mm 44.5 kg
Controller shelf (ETERNUS AX4100, ETERNUS HX6100) 1,180 × 690 × 700 mm 140.0 kg
Drive shelf 2.5" type 810 × 490 × 710 mm 44.5 kg
3.5" type 810 × 490 × 710 mm 44.5 kg
60-drive type 1,180 × 690 × 700 mm 140 kg
Drive (*3) 2.5" type 160 × 278 × 106 mm Approximately 0.5 kg
3.5" type 189 × 300 × 116 mm Approximately 1.2 kg
6 drives 330 × 340 × 210 mm Approximately 6 kg
10 drives 350 × 360 × 290 mm Approximately 9 kg
Power distribution unit (540 × 380 × 310 mm) × 2 (Approximately 10 kg) × 2
To Next Page
