Fujitsu ETERNUS AX Series Guide

1. ETERNUS AX/HX Installation
Installation Specifications
Site Planning Guide14
Maximum power
consumption (*2)
Controller
shelf
3.5" type AC100 – 120V 496 W (507 VA) -
AC200 – 240V 487 W (498 VA) -
2.5" type AC100 – 120V - 615 W (631 VA)
AC200 – 240V - 606 W (620 VA)
Drive
shelf
DS212C
3.5" type
AC100 – 120V 338 W (345 VA) 338 W (345 VA)
AC200 – 240V 332 W (340 VA) 332 W (340 VA)
DS224C
2.5" type
AC100 – 120V 396 W (405 VA) 396 W (405 VA)
AC200 – 240V 389 W (398 VA) 389 W (398 VA)
DS460C 60-
drive type
AC100 – 120V - -
AC200 – 240V 1,541 W (1,558 VA) 1,541 W (1,558 VA)
Maximum configuration
(*4)
AC100 – 120V 3,596 W (3,672 VA) 3,715 W (3,796 VA)
AC200 – 240V 3,901 W (3,954 VA) 3,688 W (3,738 VA)
Maximum heat
generation (*2)
Controller
shelf
3.5" type AC100 – 120V 1,786 kJ/h -
AC200 – 240V 1,753 kJ/h -
2.5" type AC100 – 120V - 2,214 kJ/h
AC200 – 240V - 2,182 kJ/h
Drive
shelf
DS212C
3.5" type
AC100 – 120V 1,217 kJ/h 1,217 kJ/h
AC200 – 240V 1,195 kJ/h 1,195 kJ/h
DS224C
2.5" type
AC100 – 120V 1,534 kJ/h 1,426 kJ/h
AC200 – 240V 1,505 kJ/h 1,400 kJ/h
DS460C 60-
drive type
AC100 – 120V - -
AC200 – 240V 5,548 kJ/h 5,548 kJ/h
Maximum configuration
(*4)
AC100 – 120V 12,946 kJ/h 13,374 kJ/h
AC200 – 240V 14,044 kJ/h 13,277 kJ/h
Maximum amount
of exhaust air
Controller shelf - -
Drive
shelf
2.5" type / 3.5" type - -
60-drive type - -
Item ETERNUS HX2100 ETERNUS HX2200
