Chapter 3 Operation instructions
IP-9500e
43
- Status menu LAN
Status
No.
Page status Description
Key operation
/Conditions
Transition
to
Press [Enter] -----
Press [Cancel] 3-1
Press [△] 4-6
Press [▽]. 4-2
Press [Y] -----
4-1
●Status menu LAN page 1
The above figure shows a
display example.
"Static IP," "DHCP," or
"PPPoE" is displayed.
Pressing the Enter key while the Status
menu page 1 is displayed proceeds to this
page.
The current IP setting is displayed.
In the factory shipment state, "Static IP" is
displayed.
Pressing the [△] or [▽] key displays other
settings.
Press [Z] -----
Press [Enter] -----
Press [Cancel] 3-1
Press [△] 4-1
Press [▽] 4-3
Press [Y] -----
4-2
●Status menu LAN page 2
The current IP address is
displayed at the above
XXX.
The IP address that is currently set is
displayed.
When the factory shipment setting is
effective, "10.0.0.1" is displayed.
Press [Z] -----
Press [Enter] -----
Press [Cancel] 3-1
Press [△] 4-2
Press [▽] 4-4
Press [Y] -----
4-3
●Status menu LAN page 3
The current subnet mask is
displayed at the above
XXX.
The subnet mask that is currently set is
displayed.
When the factory shipment setting is
effective, "255.0.0.0" is displayed.
Press [Z] -----
Press [Enter] -----
Press [Cancel] 3-1
Press [△] 4-3
Press [▽] 4-5
Press [Y] -----
4-4
●Status menu LAN page 4
The current gateway
address is displayed at the
above XXX.
The gateway address that is currently set is
displayed.
When the factory shipment setting is
effective, "0.0.0.0" is displayed.
Press [Z] -----
Press [Enter]
-----
Press [Cancel]
3-1
Press [△]
4-4
Press [▽]
4-6
Press [Y]
-----
4-5
●Status menu LAN page 5
The above figure shows a
display example.
One of the following is
displayed:
1000Base-T Full / Half
100Base-TX Full / Half
10Base-T Full / Half
The Ethernet type that is currently set is
displayed.
When the factory shipment setting is
effective, the displayed data depends on
the connection partner.
"----" is displayed when no link is set up
because the LAN cable is not connected.
Press [Z]
-----
Press [Enter] -----
Press [Cancel] 3-1
Press [△] 4-5
Press [▽] 4-1
Press [Y] -----
4-6
●Status menu LAN page 6
"Connected" or
"Disconnected" is
displayed.
The current link status is displayed.
Press [Z] -----
2 IP address
XXX.XXX.XXX.XXX
1 Setting
Static IP
3 Subnetmask
XXX.XXX.XXX.XXX
2 Gateway address
XXX.XXX.XXX.XXX
3 Speed
1000Base-T
4 Link
Connected
