Chapter 3 Operation instructions
IP-9500e
44
- Status menu CONSOLE
Status
No.
Page status Description
Key operation
/Conditions
Transition
to
Press[Enter]
-----
Press [Cancel]
3-2
Press [△] 5-4
Press [▽] 5-2
Press [Y] -----
5-1
●Status menu console page 1
The current IP address is
displayed at the above XXX.
Pressing the Enter key while the Status
menu page 2 is displayed proceeds to
this page.
The current IP address setting is
displayed.
When the factory shipment setting is
effective, "192.168.255.253" is
displayed.
Pressing the [△] or [▽] key displays
other settings.
Press [Z] -----
Press [Enter] -----
Press [Cancel] 3-2
Press [△] 5-1
Press [▽] 5-3
Press [Y] -----
5-2
●Status menu console page 2
The current subnet mask is
displayed at the above XXX.
The subnet mask that is currently set is
displayed.
When the factory shipment setting is
effective, "255.255.255.252" is
displayed.
Press [Z] -----
Press [Enter] -----
Press [Cancel] 3-2
Press [△]
5-2
Press [▽]
5-4
Press [Y]
-----
5-3
●Status menu console page 3
The above figure shows a
display example.
One of the following is
displayed:
1000Base-T Full / Half
100Base-TX Full / Half
10Base-T Full / Half
The Ethernet type that is currently set is
displayed.
When the factory shipment setting is
effective, the displayed data depends on
the connection partner.
"----" is displayed when no link is set up
because the LAN cable is not connected.
Press [Z]
-----
Press [Enter] -----
Press [Cancel] 3-2
Press [△] 5-3
Press [▽] 5-1
Press [Y] -----
5-4
●Status menu console page 4
"Connected" or
"Disconnected" is displayed.
The current link status is displayed.
Press [Z] -----
2 IP address
XXX.XXX.XXX.XXX
3 Subnetmask
XXX.XXX.XXX.XXX
3 Speed
1000Base-T
4 Link
Connected
