Wireless LAN Function
57
No data needs to be entered in [Manda-
tory access point].
2. Enter the network name (SSID).
Enter the appropriate network name ac-
cording to the “Operation mode” to be
used.
Enter the desired network name in less
than 32 ASCII characters.
• For infrastructure connection
Select [Infrastructure-Connect to an
Access Point] of the selected “Op-
eration mode”, and assign the ap-
propriate data according to the ID
code of the Access Point to be
accessed. For Access Point setting,
refer to the manual of the Access
Point.
• For ad hoc connection
Select [Ad hoc-Connect directly to
other computers] of the selected
“Operation mode”, and assign the
same network name to all the per-
sonal computers to be connected.
5. Click the [Next] button.
6. Set security.
1. Select [Network Authentication].
Depending on the ID code of the Access
Point to be accessed, select whether you
desire network authentication.
• [No]
Select [No] if you desire open-sys-
tem authentication or open-key au-
thentication.
• [Yes]
Select [Yes] if you desire shared-key
authentication.
2. Select [Data encryption (WEP)].
Specify the method of encoding commu-
nications data.
• “None”
Encoding is not assigned.
Network authentication cannot be se-
lected for ad hoc connection.
If [Use pass phrase] has been selected
above, enter an ASCII character string
consisting of five or thirteen characters.
The characters that can be used for [Path
phrase] are as follows:
0 - 9, A - Z, a - z
If [Use WEP Keys] has been selected,
enter a hexadecimal number consisting
of 10 or 26 characters.
The characters that can be used for [Key]
are as follows:
0 - 9, A - F
