52 Options Guide RX300 S2
Installing a LocalView module Accessible drives
Removing the FD Drive
Figure 30: Unlocking the the FD Drive module (for better visibility, the fanbox is removed)
Ê Unlock (1) the FDD module.
Ê Push the FDD module to the front (2).
1
2
