Fujitsu Primergy RX300 S2 Options Guide

RX300 S2 Options Guide 23
Preparation Opening the server
4.2 Opening the server
Figure 4: Removing the top cover
Ê Pess the two locking buttons (1) downward and remove the cover (2).
Ê Slide the cover to the rear side and remove it (2).
1
1
2

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
