Fujitsu Primergy RX300 S2 Options Guide

RX300 S2 Options Guide 71
10 RemoteView components
V CAUTION!
Observe the safety instructions in the chapter „Safety notes“ on page 15.
10.1 Installing the chipDISK
Ê Open the server as described in the chapter „Preparation“ on page 21.
Figure 47: Installing the chipDISK
Ê Connect the chipDISK to the plug-in location on the system board.
V CAUTION
Note the coding of the chipDISK and plug-in location.
Ê Close the server, connect it to the power outlet, and switch it on as described
in the chapter „Completion“ on page 107.

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
