Fujitsu Primergy RX300 S2 Options Guide

RX300 S2 Options Guide 39
Processors Replacing the processor
6.2 Replacing the processor
V CAUTION
Only processors of the same type may be used on the system board. The
second processor must have the same clock frequency and the same
cache as the first processor. For dual operation, use a suitable multipro-
cessor operating system.
Ê Open the server as described in the chapter „Preparation“ on page 21.
Ê Remove the air duct over the main memory and the processors (see
page 28.
Figure 19: Removing the heat sink
Ê Loosen the four screws in a crossover pattern.
Ê Loosen the heat sink by turning it back and forth and then lift it out.

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
