Fujitsu Primergy RX300 S2 Options Guide

RX300 S2 Options Guide 95
Converting from 1- to 2-channel version Removing 2nd SCSI backplane
13.1 Removing 2nd SCSI backplane
Ê Open the server as described in the chapter „Preparation“ on page 21.
Ê Remove all hot-plug hard disks or/and the hot-plug tape drive on the left side
(for a description see the Operating Manual).
Figure 78: Disconnecting the cables
Ê Pull out the connectors of the I
2
C cable (1), the power cable (2), and both
SCSI cables (3) from the SCSI backplane.
1
2
3
3

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
