Fujitsu Primergy RX300 S2 Options Guide

RX300 S2 Options Guide 93
13 Converting from 1- to 2-channel
version
V CAUTION!
Observe the safety instructions in the chapter „Safety notes“ on page 15.
I For the PRIMERGY RX300 S2 the SCSI backplane is separated into two
parts. The 1st SCSI backplane can stay installed for both configurations.
For upgrading you must change the second SCSI backplane. Die 1-
channel backplane must be exchanged for a 2-channel SCSI backplane
(which is the same as the SCSI backplane installed in the first SCSI
backplane holder yet) and the SCSI cabling must be exchanged.
Figure 76: Second SCSI backplane for 1-channel configuration

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
