Fujitsu Primergy RX300 S2 Options Guide

92 Options Guide RX300 S2
Installing a parallel interface Parallel interface
Figure 75: Installing the riser card with parallel interface.
Ê Insert the riser card.
Ê Route the cable.
Ê Connect the cable to the system board.
Ê Close the server, connect it to the power outlet, and switch it on as described
in the chapter „Completion“ on page 107.

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
