Fujitsu Primergy RX300 S2 - Installing a FD Drive

46 Options Guide RX300 S2
Installing a FD drive Accessible drives
8.1 Installing a FD drive
Ê Open the server as described in the chapter „Preparation“ on page 21.
Removing a FD drive dummy module
Figure 24: Unlocking the FD drive dummy module
Ê Unlock the FD drive dummy module (1).
Ê Push the FD drive dummy module to the front (2).
1
2
