Fujitsu Primergy RX300 S2 Options Guide

70 Options Guide RX300 S2
Population of the PCI slots PCI slots
9.3 Population of the PCI slots
Standard configuration with 5 low profile slots
Riser configuration with 3 standard profile slots
Adapter class Adapter priority Slot (order)
External SCSI interface 1 1
Parallel port 2 5
FC (QLA2340, LP9802) 3 5, 4
RSB 4 3, 4, 5
LAN Controller 5 5, 4, 3, 2, 1
RAID 6 5, 4, 3, 2, 1
SCSI 7 5, 4, 3, 2, 1
Adapter class Adapter priority Slot (order)
External SCSI interface 1 6
Parallel Port 2 8
RAID 3 8, 7, 6
FC (QLA2340, LP9802) 3 7, 6
RSB 4 6, 7, 8
LAN Controller 5 7, 6
SCSI 7 7, 6

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
