4 U41221-J-Z156-1-74
Technical Data Introduction
● Configurations
This part of the manual gives configuration examples.
● Installation
The activities needed to install and commission the storage subsystem are
described.
● Troubleshooting
This chapter contains advice on solving problems that occur on commis-
sioning or during the operation of the storage subsystem.
1.4 Technical Data
Electrical Characteristics
Rated voltage 100 V - 240 V
Tolerance of the rated voltage +6 % / -10 %
Rated frequency 50 Hz / 60 Hz
Rated current max. 1.3 A at 240 V
max. 3.1 A at 100 V
Power consumption
Active power (= heat transfer) max. 305 W
Apparent power max. 310 VA
Power factor (PF) 0.95-0.99
Dimensions and
Weight
Floorstand model Rack model
Height 481mm 133 mm
Width 200 mm without legs
280 mm with legs
483 mm
Depth 692 mm 646 mm
Weight max. 32 kg max. 30 kg
