U41221-J-Z156-1-74 43
FC Hard Disk Drives Identification Marks and Loop Addresses
7.4 Identification Marks and Loop Addresses
The identification of the hard disk drives with marks as HDD1 through HDD14
must be performed from the bottom up (floorstand model) or from left to right
(rack model).
The loop addresses of the FC hard disk drives are hardware-predefined as
follows:
HDD 1234567891011121314
ID (Dec.) 012 3 45678910111213
ID (hex) 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D
Table 7: Address IDs
