Operating and Indicator Elements The Front
Optical Waveguide Color Meaning
Power supply status none No mains voltage present.
green POWER OK
Equipment switched ON, all installed
power supply units OK.
yellow POWER WARNING
One power supply unit has failed.
orange STANDBY
Equipment switched OFF, mains voltage
present.
Cooling status
V CAUTION!
The PRIMERGY S60
storage subsystem
(without Remote Service
Board) switches OFF at
an interior temperature of
55°C (see section
“Cooling status LED lights
orange” on page 73).
green Cooling OK
All installed fans and the interior temper-
ature are OK.
yellow Fan warning
One fan has failed.
The temperature is OK.
orange Cooling fault
All the fans have failed or the interior
temperature exceeds the permissible
values.
Server management
status (global SES
indicator)
none No status indication
orange Identification indication
(can be activated manually from
ServerView).
For troubleshooting see section “Server
Management Status LED lights perma-
nently” on page 74.
Table 1: Meaning of the Operating Status LEDs Indication
