Introducing the Encore/Eclipse Series Encore S Series
Page 10 MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011
Americans with Disabilities Act (ADA) Requirements
To meet the reach requirements as specified by the Americans with Disabilities Act,
the island of the dispenser must not be higher than 6” tall.
IMPORTANT INFORMATION
Figure 3-4: ADA Requirements
42’
48”
6”
