MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011 Page 27
Additional Security in Encore S Series Units Preparing to Service Units
Additional Security in Encore S Series Units
The Encore S series units have been designed with security in mind to prevent/minimize the
probability of fuel theft.
In addition to security features that have been built into the Encore units so far, such as the
CIM, lower panel locks and keys, and the Personal Identification Number (PIN) code-secured
Manager Keypad, the Encore S series unit comes with the following additional security
features:
• A separate printer door (with a lock) that restricts access to the inside of the unit.
• A security latch that may be used to secure the lower part of the main door (bezel). See
Figure 4-1 on page 28.
• An improved design that does not enable a person to open the main door without first
removing the lower panel door.
• An option to install hinge sensors that will send an alert to the POS whenever the
main/lower panel doors are opened.
To optimally utilize the additional security features installed in the Encore S series units,
proceed as follows:
1 Close and lock the main door, using the main door lock located to the left of the main door. To
identify the location of the lock, see
Figure 3-1 on page 7.
Notes: 1) When closing the main door, remember to push inward and then lock the door to
ensure that the inner lining is sealed to prevent rain water from seeping into the
main door.
2) If you do not close the main door properly, you will have problems when removing or
reinstalling the lower panel door.
2 Place the security latch in the locked position.
Note: You may use a padlock (optional) to secure the latch.
