MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011 Page 55
Periodic Maintenance Requirements Maintaining Units
Changing the Receipt Paper in USB Sliding Printer for Encore S Series
Enhanced Bezel (M07885A001)
To change the receipt paper in the printer, proceed as follows:
Note: The USB Sliding Printer for Encore S Series E-CIM (M07885A001) is capable of
holding a receipt paper roll of 6 inches.
1 Insert the printer key and turn it to the left to open the printer door.
Figure 5-19: Inserting the Printer Key
2 Open the printer door and pull out the slide completely.
Figure 5-20: Opening the Door and Pulling out the Slide
(i)
(ii)
