Maintaining Units Periodic Maintenance Requirements
Page 56 MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011
3 Pull the empty paper spindle from the cable clamp.
Note: The unit is shipped with the spindle held by the cable clamp.
Figure 5-21: Pulling the Paper Spindle
(i)
(ii)
Figure 5-22: Spindle
Spindle
Lanyard
