MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011 Page 17
Common Functions Introducing the Encore/Eclipse Series
The location of data in the displays is shown in Figure 3-8.
Note: To see illustrations that show the location of these displays, refer to
“Introducing the Encore/Eclipse Series” on page 7.
Figure 3-8: Location of Data
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4
Main Display
PPU Display
Money Display
Volume Display
Side
Grade
Use the Manager’s Keypad and the instructions in the following table to display pump totals
for Encore and Eclipse units.
Grade Number Reference Chart
To Press Result
Display totals • $Total for Money
• Vol Total for Volume
Side digit flashes
Select side • 1—Side 1 (A)
• 2—Side 2 (B)
Side digit flashes
Select grade ENTER and 1-8 for grades 1-8. Grade digit flashes
Toggle between side and grade ENTER Toggles flashing digit between
side and grade digit
Exit CLEAR Exits the operation
Type Grade
Encore 300
Dual 1
Quad (Four-hose) 1, 2
Multi-Product Dispenser (MPD) 1, 2, 3
6H Bl 1, 2, 3
3 + 0 Bl 1, 2, 3
3+1 Bl 1, 2, 3, 6
5+0 Bl 1, 2, 3, 4, 5
Encore 500
Dual 1
Quad 1, 2
MPD 1, 2, 3
3 + 0 Bl 1, 2, 3
6H Bl 1, 2, 3
4 Grade MPD 1, 2, 3, 4
5 + 0 Bl 1, 2, 3, 4, 5
3 +1 Bl 1, 2, 3, 6
To Next Page
