Keep your fingers or hair from coming into contact with the gears on the side of the printer,
as it could result in an injury.
CAUTION
Gears on the side
of the Printer
Right Blue Pin
MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011 Page 51
Periodic Maintenance Requirements Maintaining Units
5 Feed the paper into the printer inlet following the direction of arrows on the printer.
Note: If the gears rattle when loading the paper, press trigger and feed the paper
simultaneously.
The paper will automatically feed through the printer after the initial feed is done manually.
Changing the Receipt Paper in USB Sliding Printer (M06972A001)
Figure 5-14: USB Sliding Printer
To Next Page
