Maintaining Units Periodic Maintenance Requirements
Page 48 MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011
7 Close the cover over the printer mechanism completely. Any gaps may lead to paper jams
later.
Figure 5-8: Printer Cover - Closing
Printer Cover in its
Closed Position
8 Tear the excess paper at the chute opening.
Changing the Receipt Paper in USB Printer (M04119A001)
Figure 5-9: USB Printer
Blue Pin
Paper Bucket
Chute
Avoid touching any wires or circuit boards during paper replacement, as static
electricity from your fingers may damage the unit.
CAUTION
