Maintaining Units Periodic Maintenance Requirements
Page 52 MDE-3893P Encore® and Eclipse® Series Owner’s Manual · December 2011
To replace the receipt paper in the sliding printer, proceed as follows:
1 Remove the paper roll core.
Note: To prevent paper from being trapped inside the printer, the printer automatically
reverses the last short receipt left from the paper roll. Remove such receipts along with
the paper roll core, if present.
Figure 5-15: Paper Removal
Paper must be removed properly to
prevent paper jamming
Figure 5-16: Printer in the Encore S Series Unit
Printer Control Module
Avoid touching any wires or circuit boards during paper replacement, as static
electricity from your fingers may damage the unit.
CAUTION
To Next Page
