Installation Specifications
382
Installation Specifications
The following table summarizes the installation specifications of the ScanSnap.
Item Specification
Outer dimensions (Width × Depth × Height) Minimum: 273 × 47.5 × 34 (mm) / 10.7 × 1.9 × 1.3 (in.)
(when the feed guide is closed)
Maximum: 273 × 77 × 52 (mm) / 10.7 × 3 × 2 (in.)
(when the feed guide or the output guide is open)
Weight 350g (approx. 0.77 lb.)
Input power Voltage 5V
Power consumption During operation: 2.5 W or less
During standby: 1.0 W or less
Temperature / humidity
allowable ranges
Temperature During operation: 5 to 35°C / 41 to 95°F
During standby: -20 to 60°C / -4 to 140 °F
During storage/transportation: -20 to 60°C / -4 to 140°F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
52 mm
(2 in.)
77 mm (3 in.)
273 mm (10.7 in.)
