APPENDIX 1 MENU TREE
[Setting] tab
Sounder Interference (Off, Low, Medium, High, Auto)
, F: Yes
Color Erase (0 to 50%, 0%)
, F: Yes
White Edge (Off, 1
to
10)
, F: Yes
Clutter, HF Clutter (0
to
100%, 40%)
F: Yes
HF Curve (Std, Linear)
LF Clutter (0
to
100%, 40%)
LF Curve (Std, Linear)
TVG, HF TVG Level (0
to
9, 3)
F: Yes
HF TVG Distance (100
to
3000 ft, 600 ft)
LF TVG Level (0
to
9, 3)
LF TVG Distance (100
to
3000 ft, 600 ft)
STC, HF STC (0
to
10, 0)
F: Yes
LF STC (0
to
10, 0)
Pic. Advance (Stop, 1/4, 1/2, ×1, ×2, ×4)
, F: Yes
Smoothing (Off, 1
to
8, 3)
, F: Yes
Bottom Zone
, F: Yes
Display A-Scope (Off, Normal, Peak)
, F: Yes
Temp Graph (Off, Narrow, Normal, Wide)
, F: Yes
Temp Color (Std, White, Red, Black, Yellow)
, F: Yes
Display Division ( , )
, F: Yes
Window Size (3:1, 2:1, 1:1, 1:2, 1:3)
, F: Yes
Zoom Mode (Bottom Lock, Bottom Zoom, Marker Zoom, Discrim Zoom)
, F: Yes
Zoom Marker (Off, On)
, F: Yes
Colors (8, 16, 64)
, F: Yes
Hue (Std, Hue1
to
Hue5, Custom)
, F: Yes
Back Ground (White, Light Blue, Blue, Dark Blue, Black)
, F: Yes
Window Color (Day, Night)
, F: Yes
Depth Size (Off, Normal, Zoom)
, F: Yes
Depth Scale (Right, Center, Off)
, F: Yes
Color Bar (Off, On)
, F: Yes
Function Display (Off, Key (F1/F2), Key (1/2/3))
, F: Yes
Mode&Gain Display (Off, On)
, F: Yes
Measurement ACCU-FISH (Off, Graph*, Symbol
)
, F: Yes
[Graph Display]
Graph Style* (Horizontal, Vertical)
, F: Yes
Graph Size* (Small, Middle, Large)
, F: Yes
Graph Location* (Upper Left, Lower Left, Upper Right, Lower Right)
, F: Yes
Graph Scale End
* (16inch, 24inch, 32inch, 39inch, 47inch, 63inch, 79inch), F: Yes
Distributed Scale Start* (0
to
5%, 3%)
, F: Yes
Distributed Scale End* (10
to
100%, 50%)
, F: Yes
Number of graph bars
*
(Max. 16 bars, Max. 8 bars, Max. 4 bars ), F: Yes
Transparency* (Off, 1
to
4)
, F: Yes
Updating Cycle* (500 msec, 700 msec, 1 s, 2 s, 3 s)
, F: Yes
[Mark Display]
Fish Info (Fish Size, Depth)
, F: Yes
Fish Symbols (Off, Fish Mark, Point Mark)
, F: Yes
Alarm Bottom (Off, On), From (0 to 9000 ft, 0 ft)
, F: Yes
F: Yes
Span (1 to 9000 ft, 10 ft)
, F: Yes
Fish (Normal) (Off, Defined Area, All Area), From (0 to 9000 ft, 0 ft)
, F: Yes
F: Yes
Span (1 to 9000 ft, 10 ft)
, F: Yes
Fish (B/L) (Off, On), From (0.0 to 600.0 ft, 0.0 ft)
, F: Yes
F: Yes
Span (0.1 to 600.0 ft, 1.0 ft)
, F: Yes
Fish Level (Weak, Medium, Strong)
, F: Yes
Temperature (Off, Inside, Outside), From (20.0 to 110.0 °F, 65.0 °F)
, F: Yes
F: Yes
Span (0.1 to 30.0 °F, 1.0 °F)
, F: Yes
Fish Size (Off, On), From (4 to 40 inch, 4 inch)
, F: Yes
F: Yes
Span (1 to 40 inch, 12 inch)
, F: Yes
Bold Italic:Default setting
F: Yes:Items which can
be progammed to the F1
and F2 key.
*: Available with FCV-1900G
[Setting]
To Next Page
