APPENDIX 1 MENU TREE
AP-3
[LF]
TX Pulse Edge
*
1
(Off, On)
,
F: Yes
TX Pulse
*
1
(1/4, 1/2, Std, ×2, Manual)
,
F: Yes
Pluse Length
*
1
(0.01 to 5.00 msec, 0.05 msec)
,
F: Yes
RX Band
*
1
(Narrow, Std, Wide, Manual)
,
F: Yes
RX Band Width
*
1
(0.2 to 25.0 kHz, 0.2 kHz)
,
F: Yes
Key Key Beep (Off, On)
,
F: Yes
Language (English, Others)
,
F: Yes
Units Depth (m, ft, fa, HR, pb)
,
F: Yes
Speed (kn, km/h, mph)
,
F: Yes
Temp (°C, °F)
,
F: Yes
Fish Size (inch, cm)
,
F: Yes
NMEA Port
NMEA1, F: No
Set&Monitor
NMEA2, F: No
SC, F: No
CIF, F: No
Calib Sound Speed (200.0 to 2000.0 m/s, 1500.0 m/s)
,
F: Yes
Temp (-20.0 to +20.0 °F, +00.0 °F)
,
F: Yes
Bottom Level, HF Bottom Level (-40 to +40, +0)
F: Yes LF Bottom Level (-40 to +40, +0)
Zero Line Rejection (Off, On)
,
F: Yes
Zero Line Area (0.4 to 3.0 m, 0.4 m)
,
F: Yes
Zero Line Fill (Off, On)
,
F: Yes
Draft, HF Draft (-30.0 to +99.9 ft, +00.0 ft)
F: Yes LF Draft (-30.0 to +99.9 ft, +00.0 ft)
Gain ADJ HF Gain ADJ (-50 to +50, +0)
F: Yes LF Gain ADJ (-50 to +50, +0)
Fish Size (-80 to +500, +0)
,
F: Yes
Stabilization
Stabilization (Off, On)
,
F: Yes
Stabilization Sensor (SC-50, SC-110, SC-30)
,
F: Yes
Stabilization Area (0 to 15 m, 15 m)
,
F: Yes
[HF]
TD fore-aft (-100.0 to +100.0 m, +0.0 m)
,
F: Yes
TD port-stbd (-100.0 to +100.0 m, +0.0 m)
,
F: Yes
ANT TD height (0.0 to 100.0 m, 0.0 m)
,
F: Yes
[LF]
TD fore-aft (-100.0 to +100.0 m, +0.0 m)
,
F: Yes
TD port-stbd (-100.0 to +100.0 m, +0.0 m)
,
F: Yes
ANT TD height (0.0 to 100.0 m, 0.0 m)
,
F: Yes
Tankenmaru
Tankenmaru Output (Off, HF, LF)
,
F: Yes
Setting
*
2
Pic. Sync (Off, On)
,
F: Yes
Tests Diagnostic Test, F: No
LCD Test, F: No
Save Setting
Save Setting (User1, User2)
,
F: Yes
Read Setting (General, Surface, User1, User2)
,
F: Yes
Save Setting External (Yes, No)
,
F: Yes
Read Setting External, F: No
Image Replay
Delete All (Yes, No)
,
F: Yes
External Output (Yes, No)
,
F: Yes
External USB Replay, F: No
*
2
: Available when the Tankenmaru
system is connected.
*
1
: Available when the transmission
mode is [Std] mode.
