FUTABA 14SG - Page 44

43
<Receiver and Servo Installation>
● FASSTest12CH
● FASSTest14CH/FASSTMULTI/FASST7CH/S-FHSS
CH
All Other H-4, H4X Swash
1 Aileron Aileron
2 Elevator Elevator
3 Throttle Throttle
4 Rudder Rudder
5 Gyro/RUD Gyro/RUD
6 Pitch Pitch
7 Governor Governor
8 Needle Elevator2
9 Gyro2/AIL Gyro2/AIL
10 Gyro3/ELE Gyro3/ELE
11 AUX1 AUX1
12 AUX1 AUX1
DG1 SW SW
DG2 SW SW
FASST7CH S-FHSS FASSTest14CHFASSTMULT
CH
All Other H-4, H4X Swash
1 Aileron Aileron
2 Elevator Elevator
3 Throttle Throttle
4 Rudder Elevator2
5 Pitch Pitch
6 Gyro/RUD Gyro/RUD
7 Governor Governor
8 Governor2 Rudder
9 Gyro2/AIL Gyro2/AIL
10 Gyro3/ELE Gyro3/ELE
DG1 SW SW
DG2 SW SW
FASSTest12CH
Helicopter
Ɣ6LQFHWKHFKGRHVQWZRUNRQWKHFKPRGHSOHDVHDVVLJQWKH
HOHYDWRU++;RUWKHQHHGOHDOORWKHUWRFKDQQQHOLIWKH
governor is not used.
Theoutput
CHofeach
system
Theoutput
CHofeach
system
