FUTABA 4pls User Manual

+1 ~ +100
-1 ~ -100
Wheel operation
Mild
(Negative side)
Quick
(Positive side)
Wheel operation
Servo travel
Press
Press
Press
Press
Select "EXP"
(HOME screen)
(MENU 2 screen)
(
EXP screen)
(MENU 1 screen)
Vertical cursor moves in step
with steering wheel operation.
51
Function
Exponential Adjustment "EXP"
Exponential Adjustment "EXP"
(Steering/ Throttle system)
This function is used to change the sensitivity of the servo around the neutral position.
Display to "EXP" screen by the following method:
(Preparation)
- On the EXP screen,
Select the setting item "STR" by the (JOG)
button.
1
When you want to quicken steering operation,
use the (+) button to adjust the + side. When
you want to make steering operation milder,
use the (-) button to adjust the - side.
Steering EXP adjustment
When the setting is not determined, or the
characteristics of the model are unknown,
start with 0%. (When EXP is set to 0%, servo
movement is linear.)
STR (Steering EXP)
This function is used to change the sensitivity of the
steering servo and around the neutral position. It has
no effect on the maximum servo travel.
Racers Tip
Adjustment range
-100~0~+100
Adjust button
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
2
When ending, return to the MENU1 screen by pressing the
(JOG) button.
Setting item
STR :Steering
FWD :Throttle forward side
BRK :Throttle brake/ reverse side
