Warning display
The function select switch
screen (P62) can be dis-
played from this screen.
< NO SW >
If function’s ON/OFF
switch is not selected,
<NO SW> is displayed.
83
Function
Throttle Mode "TH MODE"
(Preparation)
- Use the function select switch dial to select the switch. (p.65)
1
(Preset position setup)
- Select the setting item "THOFF" by the (JOG) button. Use
the (+) and (-) buttons to set the preset position of the throt-
tlle servo.
2
When ending, return to the MENU screen by moving the cur-
sor to the positions other than SW/DIAL and pressing the
(JOG) button
Engine Cut function adjustment
Caution
Always operate carefully before using this function.
While switch with preset function set is in the ON state, the servo (motor controller) is locked in the preset posi-
tion and does not operate even if the throttle trigger is operated. If the servo was operated at the wrong setting,
you may lose control of the car (boat).
Adjust button
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Preset position (THOFF)
0 ~ B100
Initial value: 0
Throttle off (engine cut) "THOFF"
This is a function select switch dial function. The throttle off function ON/OFF switch
must be set. The engine cut function stops the engine of a boat, etc. by operating the
throttle servo to the slow side by switch regardless of the position of the throttle trigger
and the setting of other functions (reverse function setting is effective).
An LED blinks while the neutral brake function is active.
Operation display
If the power switch is
turned on while the
throttle-off switch is on,
an audible alarm will be
heard. Immediately set
the neutral brake switch
to OFF.
The function select dial function can control the throttle-off position can be controlled
with digital dial or digital trim. (See page 65)
Dial / Trim Setting
To Next Page
