Display "SYSTEM" screen by the following method:

Press

Select

LAP LIST

(HOME screen)

(MENU 1 screen)

(TH MODE screen)

(MENU 2 screen)

101

Function

System Functions "SYSTEM"

The graphic liquid crystal screen display mode, buzzer sound and menu character mode,

etc can be set.

- "CONTRA" Liquid crystal screen contrast adjustment (20 steps)

- "BK-LHT" Liquid crystal screen backlighting display mode setup

(OFF, ON at button operation, normally ON)

- "LHT-TM" Setting of ON time (1~30 secs) when [ON at button operation] was selected above.

- "LHT-PM"Liquid crystal screen backlighting brghtness adjustment (30 steps)

- "BATT"Battery type setting (LiFe2/NiMH5/DRY4)

The T4PLS can use an optional rechargeable battery. However, the battery alarm setting is dif-

ferent from that of the dry cell battery (alkaline battery recommended). Therefore, always set the

battery type to match the power source used.

If used with the incorrect setting, the normal low battery alarm function will not work and the sys-

tem may stop before a battery alarm is generated. The usage time may also become extremely

short.

- "BUZZER"Buzzer sound tone adjustment (OFF, 100 steps)

- "OPE-TM"The power off forgotten alarm setting (OFF, 10 m)

- "MENU"Item which displays the basic menu screen in katakana characters for Japanese use.

- "DISP"HOME screen display mode setting (Telemetry data, Timer, Users name)

Setup items

CONTRA :Contrast

BK-LHT :Backlighting mode

LHT-TM :Backlighting time

LHT-PW :Backlighting brightness

BATT :Battery type

BUZZER :Buzzer tone

OPE-TM :Power off forgotten alarm

MENU :Menu screen character

DISP :HOME screen display mode
