0
Normal
+1 ~ +100
Trigger operation
Quick
-1 ~ -100
Mild
Servo travel
Vertical cursor moves in step
with throttle trigger operation.
53
Function
Exponential Adjustment "EXP"
(Preparation)
- On the EXP screen make the following adjustments:
1
Select the setting item "BRK" by the (JOG) button up or
down operation.
Use the (+) button to adjust for a faster throttle response or
use the (-) button for a slower or milder throttle response.
Throttle brake side EXP adjustment
Adjustment range
-100 ~ 0 ~ +100%
Adjust button
Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
The steering and throttle EXP adjustment (RATE) can be controlled with digital dial
or digital trim. With the function select
switch dial
function. (See page 65)
Dial / Trim Setting
2
When ending, return to the MENU1 screen by pressing the
(JOG) button.
To Next Page
