ON/OFF Position (POSI)
5 ~ 95
Initial value: 50
Shows the ON/OFF state
79
Function
Gyro mixing "CPS MIX"
1
(Control system setup)
Operate the (JOG) button up and down and select the setting
item "CTRL". Use the (+) or (-) button and select the function.
"INH" : Function OFF
"CH4 FUNC" : ON/OFF by switch set at the 4th CH
"STR NT" : ON at steering neutral
"STR END" : ON at both sides of steering
"THR NT" : ON at throttle neutral
"THR FWD" : ON at throttle forward side
"THR BRK" : ON at throttle back (brake) side
"TH NT+BK" : ON at throttle neutral and back (brake) sides
2
(ON/OFF switching position selection)
Select the setting item "POSI" by the (JOG)
button up or down operation. Use the (+) or (-)
button and select the ON/OFF position. Since
the ON/OFF state is displayed at the right
side of the setting item "CTRL", setting can be
confirmed while operating the function to be
controlled (for example, throttle).
3
(ON/OFF type setup)
Select the setting item "TYPE" by the (JOG) button up or
down operation. Use the (+) or (-) button and select the type
of LED lighting. Normal ON/Off type or flashing can be se-
lected.
"NORMAL" : Normal ON/OFF type
"FLASH" : Flashing display
4
(Flashing cycle setting)
When flashing type "FLASH" was selected at the setting item
"TYPE" the flashing speed (cycle) can be set.
Select the setting item "CYCL" by the (JOG) button up or
down operation. Use the (+) or (-) button and select the flash-
ing speed (cycle).
5
When ending, return to the MENU2 screen by pressing the
(JOG) button.
Select button
- Select with the (+) or (-) but-
tons.
Adjust button
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) but-
tons simultaneously for about
1 second.
Select button
- Select with the (+) or (-) but-
tons.
Function selection (MODE)
INH, CH4 FUNC, STR NTR,
STR END, THR NT, THR FWD,
THR BRK, TH NT+BK
Function selection (TYPE)
NORMAL, FLASH
Flashing cycle (CYCL)
1 ~ 100
Initial value:50
To Next Page
