Window changes as follows.
3-2-3 Using the amplifier by stand-alone
The MPS08 allows the amplifier to operate in standalone mode. Once the set conditions are saved to the
amplifier by operating the connected PC, the monitor functions even after PC is separated from the amplifier.
To do so, follow the procedure below.
Step 1: Connect PC and make necessary settings. (Refer to Section 4-4, “Setting the Conditions”,
on page 23.)
Step 2： Save the set conditions into the amplifier. (Refer to Sections 4-5, “Saving Settings As”, and 4-6,
“Saving Settings”, on page 27.)
Step 3： Exit the measurement software. (Refer to Section 4-1, “Starting and Exiting Software”, on page 21.)
Step 4： Turn off the power to the amplifier. (Refer to Section 3-1, “Turning Power ON/OFF”, on page 19.)
Step 5： Disconnect the LAN cable.
Step 6： Turn on the power to the amplifier. (Refer to Section 3-1, “Turning Power ON/OFF”, on page 19.)
* If PC is not connected, only the alarm function is possible and the data cannot be saved in the amplifier.
Sensor sensitivity window
Returns to initial window
* Set to “192.168.2.100” by default. In the case of changing IP address, see
[6-7 Administrator Settings], on page34.
To Next Page
