9. Specifications
 List of specifications
<Pressure measuring amplifier MPS08>
Number of measurement points
8
Measurement range
0 to 200 MPa
Accuracy
±2% F.S.
Sampling period
1 ms / 5 ms / 10 ms / 20 ms
Sampling time
Up to 120 sec.
Control input
Non-voltage contact input
Control output
NPN open collector; up to 100 mA (30 V or less)
Analog output
0 to 10 V (corresponding to pressure 0 to 200 MPa)
Output impedance: About 100 
Internally stored data
Data for one settings file (written to non-volatile memory)
(Waveform data and numerical data are not stored in the amplifier.)
Operating ambient temperature
0 to +50°C
Operating ambient humidity
35 to 85%RH (no condensation)
Vibration resistance
10 to 55 Hz, double amplitude 1.5 mm, 2 hours in each direction of X, Y,
and Z
Warm-up time
About 30 minutes
Power specifications
Dedicated AC adaptor should be used.
Input: 100 to 240 VAC, 1.2 to 0.5 A
Weight
About 1,900 g
<Junction box UJPO4>
Connected sensor
SS or EPS series of Futaba Corporation
(The EPS series requires a conversion adaptor sold separately.)
Operating temperature range
0 to +70°C
Vibration resistance
10 to 55 Hz, double amplitude 1.5 mm, 2 hours in each direction of X, Y,
and Z
Weight
About 160 g
<Junction cable WJPO430> <LAN cable WCL0020>
Total length
3 m
Specification
CAT 7
Operating temperature range
0 to +70°C
Total length
2 m
Weight
About 160 g
Operating temperature range
0 to 40°C
<AC adaptor ES0024010> <Signal I/O cable WCI005>
Total length
3.1 m
Total length
0.5 m
External dimensions
(main unit)
146  76  43 [mm]
Operating temperature range
0 to +40°C
Operating temperature range
0 to +40°C
Power specifications
Input: 100 to 240 VAC,
1.2 to 0.5 A
Output: 24 VDC, 4.16 A
Weight
About 710 g
