10 Appendix C (Device Specifications)

Main Control Processor Unit (MCPU)

Part #: MSC1214

Internal ADC Resolution: 24 bits

Sampling Rate: 60 SPS

Application: Diagnostic mode

DAC Resolution: * 16 bits

DAC Accuracy: * 0.02% of FSR (Factory Calibrated)

DAC Non linearity:* 0.1% of FSR (Factory Calibrated)

Application:* Voltage output/ Current output

Analog to Digital Converter (ADC)

Part #: AD7190

Recommended Load: 30 to 30000 Ω

Bridge Excitation: 5.000 V ± 1 mV (limited current to 160 mA)

Input Range: ±2.5V (0-500 mV/V) Channel 1 for bridge

Input Range: ±12 V Channel 2 for Voltage/Current input

Sampling rate: up to 4800 SPS

Non linearity: ± 5 PPM for FSR

Offset Drift vs. temperature: ± 5 PPM/°C

Span Drift vs. temperature: ± 5 PPM/°C

Application: Signal measurement

Voltage Reference

Part #: MAX6126AASA25+

Accuracy: ± 0.02%

Nominal Voltage: 2.5 V

Temperature Shift: ± 3 PPM/°C

Application: Reference Voltage / Excitation voltage

Power Requirement

Power Supply Adapter: 15 VDC/ 1.2 A

Solid State Relays

Part #: G3VM-2F

Application: Alarm relay 1, 2

Maximum Output Voltage: 250 V (AC or DC)

Maximum Output Current: 120 mA

Note: Internally limited and protected to 110 V/100 mA
