Whenever the Bridge Input is enabled a check mark showing that this feature is enabled will be seen on
the display.
Important notice: Bridge sensors are internally connected to input number 1, current sensors are
connected to input number 2 and voltage sensors are connected to input number 3. Enabling a different
type of input can result in incorrect measurements.
7.5.9 Voltage Input
Scroll to “VOLTAGE INPUT” from “INTERFACE” using the▲▼ keys and press ENTER.
Use the◄►keys to either disable or enable the voltage input.
Depending on the type of sensor defined in the current sensor profile, a warning message will be
displayed when attempting to enable an input type which is not matched with the sensor configuration.
For example, if the active channel is defined as a bridge input the following warning message will appear
on the screen when activating a different input setting:
POWER OUTPUT
BRIDGE INPUT
► VOLTAGE INPUT
CURRENT INPUT
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
