7.5.5 Voltage Output
Scroll to “VOLTAGE OUTPUT” from “INTERFACE” using the▲▼ keys and press ENTER.
Use the◄► keys to either disable or enable the Voltage Output activity.
The configuration of the Voltage Output should be set under the output config menu. Refer to section
(6.4.4) for more details.
A prompt will be shown to set this value as a default setting.
Whenever the Voltage Output is enabled a check mark showing that this feature is enabled will be seen
on the display.
RELAY1 OUTPUT
RELAY2 OUTPUT
► VOLTAGE OUTPUT
CURRENT OUTPUT
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
<YES> <NO>
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
