7.1.3.9.2 First Valley THD
Scroll to “FIRST VY (THD)” from “LIMIT & THD” using the ▲▼ keys and press ENTER.
Use the arrow keys to move the cursor among the digits and select the desired number for the First
Valley. The sign value can also be changed from positive to negative in case a bi-directional sensor is
configured.
A confirmation message will be displayed confirming operation was successfully executed.
(See Figures no.1 and 2 on page 44 for examples of threshold levels on one directional and two directional
sensors).
FIRST PK (THD)
► FIRST VY (THD)
MIN / MAX DIFF
ALARM LIMIT HI
SELECT DESIRED
VALUE
USING ARROW KEYS
[+030.00%]
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
