7.5.7 Power Output
Scroll to “POWER OUTPUT” from “INTERFACE” options using the▲▼ keys and press ENTER.
Use the◄►keys to either disable or enable the Power Output.
Depending on the type of sensor that has already defined in the current sensor profile, a warning
message will be displayed when attempting to enable an input type which is not matched with the sensor
configuration. For example, if the active channel 2 is defined as a bridge input the following warning
message will appear on the screen when activating the Power Output:
Whenever the Power Output is enabled a check mark showing that this feature is enabled will be seen on
the display.
VOLTAGE OUTPUT
CURRENT OUTPUT
► POWER OUTPUT
BRIDGE INPUT
WARNING!
EXISTING SETTING
MAY BE CHANGED
ACCEPT CANCEL
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
