7.1.3.9.5 Alarm Limit Low
Scroll to “ALARM LIMIT LO” from “LIMIT & THD” using the ▲▼ keys and press ENTER.
Use the arrow keys to move the cursor among the digits and select the desired number for the Alarm
Limit Low. The sign value can also be changed from positive to negative in case a bi-directional sensor is
configured.
A confirmation message will be displayed confirming operation was successfully executed.
(See Figures no. 4 and 5 on page 49 for examples of alarm threshold levels for one directional and two
directional sensors).
MIN/MAX DIFF
A ALARM LIMIT HI
► ALARM LIMIT LO
AUTO RST (SEC)
SELECT DESIRED
VALUE
USING ARROW KEYS
[+010.00%]
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
