7.1.3.2 Direction
Scroll to “DIRECTION” from “NEW CHANNEL” using the▲▼ keys and press ENTER. “DIRECTION”
can also be selected from “EDIT CHANNEL” to make modifications on the existing channels except
channel one.
Using the ◄►keys on the keypad select either uni-direction or bi-direction.
► DIRECTION
UNIT SELECTION
SENSOR CAPACITY
SENSITIVITY(+)
SELECT DESIRED
DIRECTION TYPE
USING ◄,► KEYS
[UNI-DIRECTION]
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
