7.5.4 Relay 2 Output

Scroll to “RELAY OUTPUT2” from “INTERFACE” using the▲▼ keys and press ENTER.

Use the ◄►keys to either disable or enable the Relay 2.

The configuration of the Relay 2 Output should be set under the output config menu. Refer to section

(6.4.3) for more details.

Relay 2 is mapped to alarm low and will be affected by the alarm settings under the system settings

menu. Refer to section (6.2.8) for more details.

A prompt will be shown to set this value as a default setting.

Whenever the Relay 2 Output is enabled a check mark showing that this feature is enabled will be seen

on the display.

WOULD YOU LIKE

TO SAVE AS

DEFAULT?

SELECT DESIRED

ACTIVITY

USING ◄,► KEYS

[ENABLE]

ASCII OUTPUT

RELAY1 OUTPUT

► RELAY2 OUTPUT

VOLTAGE OUTPUT
