12 Appendix E (System Performance)
Specifications:
Parameter
ADC
Unit
Output Data Rate
5 to 4800
Hz nom
No Missing Codes
24
Bits min
Resolution
See the following RMS Noise and
Resolution Table
RMS Noise and Output Data Rates
See the following RMS Noise and
Resolution Table
Integral Nonlinearity
±5 (Current or Voltage Input)
±15 (Bridge Input)
ppm of FSR max
ppm of FSR max
Offset Error
±0.58
µV/ typ
Offset Error Drift vs. Temperature
±0.78
nV/°C typ
Offset Error drift vs. Time
25
nV/1000 hours typ
Gain Error
±0.005 (Current or Voltage Input)
±0.0075 (Bridge input)
% max
%typ
Gain Drift vs. Temperature
±1
ppm/°C typ
Gain Drift vs. Time
10 (Current or Voltage Input)
ppm/1000 hours typ
Power Supply Rejection
95 (Current or Voltage Input)
100 (Bridge input)
dB typ
dB min
Common Mode rejection
@ DC
@50Hz, 60Hz
@50Hz, 60Hz
100 (Current or Voltage Input)
110 (Bridge input)
120
120
dB min
dB min
dB min
dB min
Normal Mode Rejection
120 (10 Hz output data rate)
82 (50 Hz output data rate)
dB min
dB min
Normal Mode Rejection
Common Mode Rejection
Reference Detect Levels
Same as for analog inputs
95
0.3
0.6
dB typ
V min
V max
