7.1.3.9.1 First Peak THD
Scroll to “FIRST PK THD” from “LIMIT & THD” using the▲▼ keys and press ENTER.
Use the arrow keys to move the cursor among the digits and select the desired number for the First Peak.
The sign value can also be changed from positive to negative in case a bi-directional sensor is configured.
A confirmation message will be displayed confirming operation was successfully executed.
(See Figures no.1 and 2 on page 44 for examples of threshold levels on one directional and two directional
sensors).
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
VALUE
USING ARROW KEYS
[+050.00%]
► FIRST PK (THD)
FIRST VY (THD)
MIN / MAX DIFF
ALARM LIMIT HI
