7.1.3.3.2 Torque
Scroll to “TORQUE” from “UNIT SELECTION” using the▲▼ keys and press ENTER. The following
options for torque can be selected: g-mm, g-cm, g-m, kg-cm, kg-m, N-mm, N-cm, N-m, kN-m, in-oz, in-
lb, and ft-lb. Once the desired torque unit is selected, the following message will be shown.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
ENGINEERING UNIT
USING ◄,► KEYS
[g-mm]
FORCE (MASS)
► TORQUE
PRESSURE
DISPLACEMENT
