7.1.3.9.3 MIN/MAX Differentiation

Scroll to “MIN / MAX DIFF” from “LIMIT & THD” using the▲▼ keys and press ENTER.

Use the arrow keys to move the cursor among the digits and select the desired number for the Min/Max

Differentiations. The sign value can also be changed from positive to negative in case a bi-directional

sensor is configured.

A confirmation message will be displayed confirming operation was successfully executed.

(See Figure no.3 on page 46 for examples of Min/Max Differentiation).

OPERATION

WAS EXECUTED

SUCCESSFULLY

(HIT ENTER/BACK)

SELECT DESIRED

VALUE

USING ARROW KEYS

[+010.00%]

FIRST PK (THD)

FIRST VY (THD)

► MIN / MAX DIFF

ALARM LIMIT HI
