7.4.3 Alarm Relay 2
Alarm relay 2 is a solid state relay with a voltage / current rating of 110V/100mA. Alarm relay 2 has been
mapped to alarm low.
Scroll to “ALARM RELAY2” from “OUTPUT CONFIG” using the▲▼ keys and press ENTER.
Use the◄►keys to set the alarm relay 2 either to be normally open or normally close.
A prompt will be shown to set this value as a default setting.
SELECT DESIRED
RELAY CONFIG
USING ◄,► KEYS
[NORMALLY OPEN]
DIGITAL ASCII
ALARM RELAY1
► ALARM RELAY2
VOLTAGE CONFIG
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
<YES> <NO>
